react-drizzle

A react library to help sequence reveal animations on scroll.

Install

npm install --save react-drizzle

Requires Peer Dependency: gsap

npm install --save gsap

Usage

import React, { Component } from 'react'

import Drizzle, { DrizzleSettings } from 'react-drizzle'

class Example extends Component {
  render() {
    return (
      <DrizzleSettings speed={2}>
        <Drizzle type="text" group="my-group-namespace">
          <h1>
            Text you<br></br> want to<br></br>Animate
          </h1>
        </Drizzle>

        <Drizzle type="fade-up" group="my-group-namespace">
          {/* it will wait to load image before revealing the group */}
          <img
            width="130"
            height="auto"
            src="https://images.unsplash.com/photo-1532264523420-881a47db012d?ixlib=rb-1.2.1&ixid=eyJhcHBfaWQiOjEyMDd9&auto=format&fit=crop&w=500&q=100"
          ></img>
        </Drizzle>

        <Drizzle type="fade-up" group="second-group">
          <img
            width="130"
            height="auto"
            src="https://images.unsplash.com/photo-1532264523420-881a47db012d?ixlib=rb-1.2.1&ixid=eyJhcHBfaWQiOjEyMDd9&auto=format&fit=crop&w=500&q=100"
          ></img>
        </Drizzle>
      </DrizzleSettings>
    )
  }
}

Attributes

<Drizzle>

• type: fade or text. Can take a direction:
  • -up, -down, -left, -right, ex: type="fade-down"
• order: Number - if this isn't set, it picks the order based off creation order. Elements with an order set always rank higher than elements without an order. The plugin sets a calculated order — for example, if two elements have the order 1, 5, 7, the calculated orders get set to 0, 1, 2.
• speed: Number in seconds (default: 1) - the time it takes for a single Drizzle element to appear. This is multiplied by its calculated order.
• delay: Number in seconds (default: 0) - the amount of time to wait to reveal the item, after it is ready to reveal.
• distance: Number - pixel distance (default: 25). Used for movement, such as a fade-up
• onAppear: Function - callback that triggers when the item is ready to reveal, e.g. when the item moves into view.
• visibilityRootMargin String or Number - (default: 0) Margin around the root. See Intersection Observer API
• visibilityThreshold Array or Number - (default: 0.3) Indicates at what percentage of the target's visibility the observer's callback should be executed Intersection Observer API
• containerSx: Extend sx props to the container element
• containerStyle: Extend style props to the container element
• sx: Extend sx props to the underlying animation element
• style: Extend style props to the underlying animation element

<DrizzleSettings> - global settings applied to all child <Drizzle> elements

• Can set defaults for speed, delay, distance, visibilityRootMargin, visibilityThreshold.
• staggerSpeed: Number in seconds (default: 0.1) - the time to wait between revealing Drizzle items within the group.
• ease: String (default: 'Power2.easeOut') - a GSAP tween. ex: ease={'elastic.out(1, 0.3)'}
  • GSAP Ease Visualizer
• waitForChildImages: Boolean (default: true) - doesn't reveal group until images in the group are loaded.
• textLineStaggerSpeed: Number in seconds (default: 0.1) - for type="text"; the time to wait between revealing lines of text.

Order of operations:

Drizzle is on screen, wait for staggerSpeed, wait for delay speed, then display its children.

License

MIT © UseAllFive
