Dagger

Python wrapper around the DAGMan HTCondor Python bindings for quality-of-life improvements while generating DAGs

Dagger is a fairly thin Python wrapper around the HTCondor Python bindings that simplifies the process of creating Directed Acyclic Graphs (DAGs) for HTCondor jobs. It provides a higher-level interface to define job scripts, Submit scripts, and DAG layers and dependencies. It provides the functionality to go from a fully standalone Python function directly into a DAG, without the need to manually manage any of the intermediate steps. A typical DAGMan workflow involves

  1. Writing the job script (e.g., a Python script)
  2. Writing an HTCondor submit file that defines the job (e.g., the executable, arguments,
     environment variables, etc.)
  3. Writing a DAG file that registers the job to a DAGMan Layer
  4. Repeating (1) through (3) for every DAG layer

Dagger automates this process by allowing you to define your job script, submit file, and DAG layer in a single Python script, making for easier management and less boilerplate code.

Warning

This is seriously alpha software, please use at your own risk.

Example Usage

from dagger import Dagger

# This function will be turned into a standalone script, so it needs to be self-sufficient.
# Command line parsing can happen within the function, but any arguments passed in to the
# function will _not_ be respected
def my_function():
    import numpy as np
    import argparse

    parse = argparse.ArgumentParser()
    parser.add_argument('my_input', type=int)
    args = parser.parse_args()

    out = np.sqrt(parser.my_input)
    return out


if __name__ == __main__':
    dg = Dagger(dag_dir='./path/to/dag_dir', dag_name='amazing_dag')

    # These are the variables that are typically common across all jobs
    # That will be defined within the submit file
    submit_vars = {
      'executable' : 'my_function.py',
      'arguments' : '$(my_input)', # We will defined my_input at the DAG layer stage
      'request_cpus' : 1,
      'request_memory' : '1G',
      'request_disk' : '1G'
    }

    # This should contain a list of dicts, which are the variables
    # that vary from job to job. Each element of the list will
    # create a DAG node at the same layer (sibling nodes)
    layer_vars = []
    for i in range(10): # Assume 10 jobs in this DAG layer
        layer_vars.append({
          'my_input' : i,
        })

    # Add a the function as a layer to the DAG
    dg.add_function_to_layer(my_function, submit_vars=submit_vars, layer_name = 'A', layer_vars=layer_vars)

    # Write the DAG and associated files to disk - this will generate
    # the Python script, submit file, DAGMAN file etc.
    dg.write_dag()
