Language Interpreter

Following along with the Crafting Interpreters book.

Syntactic Grammar Notes

Initial grammar

expression -> litral | unary | binary | grouping ;
literal -> NUMBER | STRING | "true" | "false" | "nil" ;
grouping -> "(" expression ")" ;
unary -> ( "-" | "!" ) expression ;
binary -> expression operator expression ;
operator -> "==" | "!=" | "<" | "<=" | "+" | "-" | "*" | "/" ;

Quoted strings are exact terminals.¹ Single lexeme whose text representation may vary are CAPITALIZED. Lowercase words are non-terminals.²

This grammar allows the production of strings like (4 + 9) / !1 == nil, but it's "ambiguous". The binary rule allows nesting in both ways, which allows you to generate the same string but with a different syntax tree. Take the string 6 / 3 - 1 for example. You can produce it by:

1. Starting with expression, picking binary
2. For the left expression, picking NUMBER, and using 6
3. For the operator, pick /
4. For the right expression, pick binary again.
5. In the nested binary pick 3 - 1

But you can also produce the same string in another way:

1. Begin with expresssion, pick binary
2. For the right expression pick NUMBER and use 1
3. For the operator pick -
4. For the left expression pick binary
5. Then in the nested binary pick 6 / 3

The string is the same, but the generated syntax tree is different. In other words there are no rules for precedence or associativity. We will apply the same precedence rules C, going from lowest to highest.

Name	Operators	Associates
Equality	== !=	Left
Comparison	> >= < <=	Left
Term	- +	Left
Factor	/ *	Left
Unary	! -	Right

We will define a separate rule for each level of precedence. Each rule below matches expressions at its precedence level or higher. For example a term can match 4 + 6, but also 3 * 2 / 6. The final primary rule covers the highest-precedence - literals and expressions inside parenthesis.

expression -> equality
equality -> comparison ( ( "==" | "!=" ) comparison )* ;
comparison -> term ( ( ">" | "<" | ">=" | "<=" ) term )* ;
term -> factor ( ( "+" | "-" ) factor )* ;
factor -> unary ( ( "*" | "/" ) unary )* ;
unary -> ( "!" | "-" ) unary | primary ;
primary -> NUMBER | STRING | "true" | "false" | "nil" | "(" expression ")" ;

Footnotes

1. Letter from the grammar's alphabet. Tokens like ==, if, 1234, etc. ↩

2. Named reference to another rule in the grammar. "Use" the rule and insert whatever it produces in its place. ↩
