xtimer: set now pointer correctly in _update_short_timers() loop

[miri64]

Contribution description

This fixes xtimer to use xtimer_now64() instead of xtimer_now() for updating the *now variable during the iteration in _update_short_timers() function. The same function is used to initialize *now in _timer_callback() below.

While using xtimer_now() in this iteration step does not hinder the proper execution of all timers in the short term timers (for those the xtimer module only looks at the start_time member, not the long_start_time member) at least for the current long term time window (I did not test higher cases), it sets the long_start_time member to 0 for all timers following in the list of timers after this iteration step. However, external modules that rely on this to be correct, e.g. evtimer, fail their calculations when trying to compare to the current value to xtimer_now64().

If the changed header becomes the new head this behavior won't show up, as it is overwritten once the update of all headers is done. However, all timers later in the list will now have the wrong values.

Testing procedure

A regression test testing this behavior is provided. Confirm the bug, by reverting the fix and running it, run it with the patch to confirm that it fixes the bug:

export BOARD="<knock yourself out>"
make -C tests/xtimer_now32_overflow flash test

Issues/PRs references

None, but should fix a known, but not reported issue, where RPL starts "spamming" DIS every minute instead of every 5 minutes after >71min.

[kaspar030]

Good job tracking this down @miri64 and @cgundogan!

[miri64]

Right. I wanted to mark @cgundogan as a co-author for the commit ^^". My mishap is now fixed ;-)

[kaspar030]

Reminds me of this: #9530 (comment) 😁

[miri64]

Right. I wanted to mark @cgundogan as a co-author for the commit ^^". My mishap is now fixed ;-)

Wrong mail address apparently :D

[kaspar030]

ACK for the fix. Please someone else take a look at the test.

[miri64]

Wrong mail address apparently :D

Fixed!

[tcschmidt]

ACK for the fix. Please someone else take a look at the test.

ACK without test? Why is the Ham playing the Chicken here?

[miri64]

ACK for the fix. Please someone else take a look at the test.

ACK without test? Why is the Ham playing the Chicken here?

Murdock should be running the test.

[kaspar030]

ACK without test?

@miri64 kept me up to date during the bug fixing. Once you see the fix, the bug is obvious.

[miri64]

Oops, flake8 reminds me that forgot to check the time during the test, as I originally wanted (which is why I imported the time module in the first place).

[miri64]

Also piggy-backed some major style issues (ignoring the >80 char per line ones) for xtimer_core.c

[JulianHolzwarth]

Because

RIOT/sys/xtimer/xtimer_core.c

Line 334 in 11f3d68

timer_list_head->long_start_time = (uint32_t)(now >> 32);

fixes the wrong long_start_time

Meaning there should be another timer in between.

[JulianHolzwarth]

This works for me: Did I understand the problem correctly?

Diff:

--- a/tests/xtimer_now32_overflow/main.c
+++ b/tests/xtimer_now32_overflow/main.c
@@ -27,9 +27,11 @@ msg_t _main_msg_queue[MAIN_MSG_QUEUE_SIZE];

 int main(void)
 {
-    xtimer_t timer1, timer2;
+    xtimer_t timer1, timer2, timer_test;
     msg_t msg1 = { .content = { .value = 1U } };
     msg_t msg2 = { .content = { .value = 2U } };
+    msg_t msg3 = { .content = { .value = 3U } };
+

     msg_init_queue(_main_msg_queue, MAIN_MSG_QUEUE_SIZE);
     /* ensure that xtimer_now64() is greater than UINT32_MAX */
@@ -40,6 +42,7 @@ int main(void)
     print_str(" #1 in 1 sec\n");
     print_str(" #2 in 3 sec\n\n");
     xtimer_set_msg64(&timer1, 1 * US_PER_SEC, &msg1, thread_getpid());
+    xtimer_set_msg64(&timer_test, 2* US_PER_SEC, &msg3, thread_getpid());
     xtimer_set_msg64(&timer2, 3 * US_PER_SEC, &msg2, thread_getpid());
     print_str("now=");
     print_u64_dec(xtimer_now64().ticks64);
@@ -50,6 +53,9 @@ int main(void)
         msg_t msg;

         msg_receive(&msg);
+        if (msg.content.value == 3U) {
+            continue;
+        }
         print_str("#");
         print_u32_dec(msg.content.value);
         print_str(":now=");

[miri64]

Yepp that was the same idea I had yesterday before going to bed and it works for me as well!

[miri64]

Added a third timer to the test. With that the bug becomes reproducible as expected.

[miri64]

If this PR will be merged, the description should be updated. In general, I'm not in favor of merging because we don't completely understand the fix.

I think I pretty much understand it now. I updated the OP as such.

[JulianHolzwarth]

Works for me and looks good to me.

[miri64]

Works for me and looks good to me.

So I can squash?

[JulianHolzwarth]

yes

[miri64]

While I wrote the test last night, I think we pretty much came to the same idea while I was keeping it behind the curtain. So I added you as a co-author :-).

[JulianHolzwarth]

thanks

[kaspar030]

The shortest reproducer should be:

1. Wait the first 2**32 usec (so every timer set has long_start_time > 0).
2. Set a timer to trigger sometime (doesn't need to be an evtmer)
3. Set an evtimer to trigger sometime after
4. Wait until 2. Has triggered, but not 3.
5. Set another evtimer to trigger after the first

This should basically instantly trigger 3.

[miri64]

The shortest reproducer should be:

1. Wait the first 2**32 usec (so every timer set has long_start_time > 0).

This alone makes the test anything but short :-P

2. Set a timer to trigger sometime (doesn't need to be an evtmer)

3. Set an evtimer to trigger sometime after

4. Wait until 2. Has triggered, but not 3.

5. Set another evtimer to trigger after the first

This should basically instantly trigger 3.

Unsurprisingly if you set 3 to trigger just after 2.

I think my test is faster, involves less modules, and has less potential to be unstable because precise timings are required.

[miri64]

@JulianHolzwarth seems to be happy about the current state of the tests and has understood the bug enough to come up with his own version of the test. So can we merge?

[miri64]

Please don't piggybag style fixes. The actual oneliner fix is hard enough to find.

Go through the list of changes, as I typically do to understand the thoughts behind a PR, and you find it pretty easy.

[kaspar030]

Go through the list of changes,

Exactly. Nicer if it's length is one, not a multiple of that. If a PR fixes an important bug, it should do just that, and not piggyback style changes. If the diff of a PR fixes one line and that is the first, with only additions of a regression test following, that's easy to parse. If a PR fixes one line but the diff shows a couple of others, it is harder to parse. Just my opinion, I guess...

I think my test is faster, involves less modules, and has less potential to be unstable because precise timings are required.

With wait 2**32min, I obviously meant "set _xtimer_current_time". :)

Anyhow, I see this as sport, so here's something even simpler, faster, involving less modules and is even less timing critical (so overall much better):

https://gist.github.com/272d7eb3e79b47a551e6c14798dfdadb

Feel free to use that instead, I can also PR that after this is merged.

[miri64]

Nah, I keep it as is now.

[kaspar030]

Ok then, let's go!

[miri64]

Backport provided in #13854
