rm-lib

RM-SCRIPTS · FiveM NUI library — dialogue, mission HUD, timers, progress bars, notifications & TextUI.

Store  ·  Documentation  ·  Discord

---

rm-lib is a client NUI library for QBCore / Qbox-style servers: Dialogue, Mission Status, Timer (timed objectives), Progress (manual 0–100 bar and optional ox-compatible duration bar), Notifications (top-right toasts), and TextUI. Frontend: React + Mantine. Backend: Lua exports. Full usage details are in this README; product-specific guides may also appear on the RM-SCRIPTS documentation.

Requirements

• ox_lib — rm-lib loads @ox_lib/init.lua as a shared script so you get cache, lib (ox), and stable player state via cache.ped. Ensure ox_lib starts before rm-lib (the manifest declares dependency 'ox_lib').

Installation

1. Place rm-lib in your resources folder.

2. Ensure ox_lib is installed and started.

3. Add to server.cfg (order matters):

   ensure ox_lib
   ensure rm-lib

4. Build the web UI if you change the React app:

   cd web
   pnpm install
   pnpm build

ox_lib and cache

Internally, dialogue camera / player alpha uses lib.getPlayerPed() from init.lua, which prefers cache.ped when ox_lib is present instead of calling PlayerPedId() repeatedly. You can use the same helper from other client scripts:

local ped = exports['rm-lib']:getPlayerPed()

---

Dialogue

Interactive dialogue with NPC name, text, and options. Captures NUI focus.

Exports

Export	Parameters	Description
dialogue	data: table, cb?: function	Opens dialogue
closeDialogue	—	Closes programmatically
isDialogueOpen	—	boolean
getDialogue	—	Current data or nil

Optional data.ped — NPC entity for scripted camera (see module).

Example

exports['rm-lib']:dialogue({
    name = 'Officer Davis',
    text = 'We need your help with a case. Are you in?',
    options = {
        { id = 'accept', label = "Yes, I'm in" },
        { id = 'decline', label = 'Not right now' },
    }
}, function(optionId)
    if optionId == nil then return end
    if optionId == 'accept' then
        -- ...
    end
end)

exports['rm-lib']:closeDialogue()

---

Mission Status

Left-side HUD: mission title, objectives with checkmarks, progress bar. Does not take NUI focus.

Exports

Export	Parameters	Description
setMission	data: table	Show / replace panel
updateObjective	objectiveId, completed	One objective
updateObjectives	objectives: table[]	Many at once
closeMission	—	Hide panel
getMission	—	Current data or nil
isMissionActive	—	boolean

Example

exports['rm-lib']:setMission({
    title = 'Drug Bust Operation',
    objectives = {
        { id = 'goto', label = 'Go to the marked location', completed = false },
        { id = 'talk', label = 'Talk to the informant', completed = false },
    }
})

exports['rm-lib']:updateObjective('goto', true)

exports['rm-lib']:closeMission()

---

Timer (timed objective HUD)

Top-center countdown (e.g. time limit for a delivery or heist). The UI counts down in NUI; optional header and text (e.g. “Timed objective” / instructions). Does not take NUI focus.

Exports

Export	Parameters	Description
showTimer	data: table, cb?: function	Start / show timer
updateTimer	data: table	Change seconds and/or header/text without hiding
closeTimer	—	Hide timer (does not call cb)

Data (showTimer / updateTimer)

Field	Type	Description
seconds	number	Required on showTimer. Remaining seconds (integer after rounding).
header	string?	Optional title row (e.g. Timed objective).
text	string?	Optional subtitle / hint.

Callback

If you pass cb to showTimer, it runs once when the countdown hits zero. It does not run if you call closeTimer first.

Examples — timer only

-- 3 minutes, no header
exports['rm-lib']:showTimer({ seconds = 180 })

-- With header + text (typical “timed objective” look)
exports['rm-lib']:showTimer({
    seconds = 300,
    header = 'Timed objective',
    text = 'Reach the drop-off before time runs out.',
}, function()
    print('Time expired — fail or trigger next phase')
end)

-- Add time or change copy while running
exports['rm-lib']:updateTimer({ seconds = 120, text = '1 minute left!' })

exports['rm-lib']:closeTimer()

---

Progress bar

Top-center 0–100 bar (same screen band as the timed objective / timer HUD). Optional header / label. If the timer and progress are both visible, the bar sits below the timer card so they do not overlap.

Exports

Export	Parameters	Description
showProgress	data: table	Show bar
updateProgress	data: table	Update value and/or labels
closeProgress	—	Hide

exports['rm-lib']:showProgress({
    progress = 25,
    header = 'Suspicion',
    label = 'Stay out of sight.',
})

exports['rm-lib']:updateProgress({ progress = 80 })

exports['rm-lib']:closeProgress()

This is not the same as ox_lib’s lib.progressBar (timed bottom bar). For that, see Duration progress below.

---

Duration progress

Bottom-center timed progress (label, percent, track). Same Lua behavior and NUI contract as ox_lib (progress / progressCancel, progressComplete callback): animations, props, cancel with X, etc.

Exports (from rm-lib)

Export	Description
progressBar	data — same table as ox_lib lib.progressBar
progressCircle	Same NUI bar as progressBar (Lua mirrors ox_lib)
cancelProgress	Cancel active bar
progressActive	boolean

local ok = exports['rm-lib']:progressBar({
    label = 'Searching...',
    duration = 5000,
    canCancel = true,
    -- anim, prop, disable, ... (same as ox_lib)
})

Using lib.progressBar / lib.progressCircle (redirect to rm-lib)

Each resource has its own Lua state. To keep calling lib.progressBar / lib.cancelProgress but show rm-lib NUI instead of ox_lib’s page, add the bridge to that resource’s manifest (after @ox_lib/init.lua). No config.lua — including the file opts in; omit it to keep ox_lib’s default UI.

shared_scripts {
    '@ox_lib/init.lua',
    '@rm-lib/shared/progress_bridge.lua',
}

Requires ensure rm-lib before that resource runs. If rm-lib is not started, the bridge falls back to ox_lib.

---

Timed objective: mission + timer together

Common pattern: show mission objectives and a time limit; when the timer ends, close the timer and react (fail, payout, etc.).

local function startTimedMission()
    exports['rm-lib']:setMission({
        title = 'Package run',
        objectives = {
            { id = 'pickup', label = 'Pick up the cargo', completed = false },
            { id = 'drop', label = 'Deliver to the marker', completed = false },
        },
    })

    exports['rm-lib']:showTimer({
        seconds = 420,
        header = 'Timed objective',
        text = 'Deliver before the clock hits zero.',
    }, function()
        exports['rm-lib']:closeTimer()
        exports['rm-lib']:closeMission()
        -- e.g. fail mission, notify player
        TriggerEvent('chat:addMessage', { args = { '^1Time up!' } })
    end)
end

While the run is active you can complete objectives as usual:

exports['rm-lib']:updateObjective('pickup', true)

If the player finishes in time, clear both:

exports['rm-lib']:closeTimer()
exports['rm-lib']:closeMission()

---

Notifications

Top-right toasts: dark rounded card, optional title, body text, type (colored icon on a soft tint), same general look as other rm-lib panels.

Types (ox_lib–style)

type	Use
info / inform	Default — info-style icon
success	Success styling
error / fail / failed	Error styling

warning is accepted for a fourth style if needed.

Exports

Export	Parameters	Description
notify	data: table	Show a toast
clearNotify	—	Remove all toasts

Data (notify)

Field	Type	Description
message or description	string	Body text (need title and/or body).
title	string?	Optional line above the message.
type	string?	info / inform, success, error / fail (default info).
duration	number?	Milliseconds (default 3000).
position, id, icon, iconColor, …	optional	Same ideas as ox_lib web notify.

Using lib.notify (redirect to rm-lib)

To keep calling lib.notify from ox_lib but show rm-lib toasts, add the notify bridge in that resource (after @ox_lib/init.lua). No config.lua — including the file opts in; omit it to keep ox_lib’s default notify UI.

shared_scripts {
    '@ox_lib/init.lua',
    '@rm-lib/shared/notify_bridge.lua',
}

Requires ensure rm-lib. If rm-lib is not started, the bridge falls back to ox_lib.

Notify + duration progress together

If you want both lib.notify and lib.progressBar routed to rm-lib in the same resource, include both bridges:

shared_scripts {
    '@ox_lib/init.lua',
    '@rm-lib/shared/notify_bridge.lua',
    '@rm-lib/shared/progress_bridge.lua',
}

Examples

exports['rm-lib']:notify({
    message = 'You drank some refreshing water',
    type = 'info',
    duration = 5000,
})

exports['rm-lib']:notify({
    title = 'ATM',
    description = 'Withdrawal complete.',
    type = 'success',
    duration = 4000,
})

exports['rm-lib']:notify({
    message = 'Not enough cash.',
    type = 'error',
})

exports['rm-lib']:clearNotify()

---

TextUI

Key + label prompt (e.g. [E] Grab bag) on the right side of the screen. Does not capture NUI focus.

Exports

Export	Parameters	Description
showTextUI	key: string, label: string	Show prompt
hideTextUI	—	Hide

exports['rm-lib']:showTextUI('E', 'Grab bag')
exports['rm-lib']:hideTextUI()

---

Optional: getPlayerPed export

Uses ox_lib cache.ped when available:

local ped = exports['rm-lib']:getPlayerPed()

Useful to align with the same caching strategy as rm-lib internals.
