⚙️ BIONIC Installation

• BIONIC is implemented in Python 3.8 and uses PyTorch and PyTorch Geometric.

• BIONIC can run on the CPU or GPU. The CPU distribution will get you up and running quickly, but the GPU distributions are significantly faster for large models (when run on a GPU).

• Currently, we provide wheels for CPU, CUDA 9.2, CUDA 10.1 and CUDA 10.2 on Linux, and CPU, CUDA 10.1 and CUDA 10.2 on Windows.

NOTE: If you run into any problems with installation, please don't hesitate to open an issue.

Pre-installation for CUDA capable BIONIC

If you are installing a CUDA capable BIONIC wheel (i.e. not CPU), first ensure you have a CUDA capable GPU and the drivers for your GPU are up to date. Then, if you don't have CUDA installed and configured on your system already, download, install and configure a BIONIC compatible CUDA version. Nvidia provides detailed instructions on how to do this for both Linux and Windows.

Installing BIONIC wheel on Graham

1. Load necessary modules on Graham:

module load nixpkgs/16.09
module load gcc/7.3.0
module load llvm/7.0.0
module load python/3.8
module load scipy-stack/2019b

2. Before installing BIONIC, it is recommended you create a virutal Python 3.8 environment using tools like the built in virtualenv command, or Anaconda. To create a python virtual environment on Graham, please do virtualenv --no-download ~/ENV. Then do source ~/ENV/bin/activate to activate the environment.

3. Make sure your virtual environment is active, then install BIONIC by running (make sure you are on graham login node)

pip install bionic_model==${VERSION}+${CUDA} -f https://bowang-lab.github.io/BIONIC/wheels.html

where ${VERSION} is the version of BIONIC you want to install (currently 0.1.0) and ${CUDA} is one of cpu, cu92, cu101, cu102, corresponding to the CPU, CUDA 9.2, CUDA 10.1 and CUDA 10.2 versions, respectively. Note, as above, that cu92 is not available on Windows.

4. If this doesn't work, download wheel from https://data.wanglab.ml/BIONIC/wheels/. And then pip install {WHEEL}.whl

5. Test BIONIC is installed properly by running bionic --help. You should see a help message.

Run BIONIC on GPU Graham

1. First, unloads all the modules so we can load cuda.

module --force purge # unloads all the modules, this is important so we can then load cuda

2. Create an interactive window for GPU job

salloc --account <account-name> --time <time-usage> --cpus-per-task=<num-cpus> --mem=<memory-usage> --gres=gpu:<num-gpus>

An example can be: salloc --account def-spai --time 00:30:00 --cpus-per-task=1 --mem=5G --gres=gpu:1

3. Load necessary modules on Graham

module load nixpkgs/16.09
module load gcc/7.3.0
module load llvm/7.0.0
module load python/3.8
module load scipy-stack/2019b
module load cuda/10.2

4. Specify cuda v10.2 path on Graham:

export LD_LIBRARY_PATH=/cvmfs/soft.computecanada.ca/easybuild/software/2017/Core/cudacore/10.2.89/lib64

5. Activate Python virtual environmentsource by doing source /project/6059997/BIONIC_ENV/bin/activate

6. Install required packages using pip install -r requirements.txt

7. Run bionic --help to test BIONIC is installed

8. Run bionic path/to/your_config_file.json for your task. If you see Using CUDA, it means your program is using GPU.

How to run Semi-supervised BIONIC on your local machine

1. Go to the virtual environment you created for BIONIC project
2. Run python -m bionic.run -config <config_file> in BIONIC/ folder. Example config files can be found under bionic/config/*.json.

How to run Semi-supervised BIONIC on Graham - Slurm

1. Clone the repo by doing git clone git@github.com:smilejennyyu/BIONIC.git
2. Create a bash script and put the following:

#!/bin/bash
#SBATCH --gres=gpu:2              # Number of GPUs (per node)
#SBATCH --mem=10G               # memory (per node)
#SBATCH --time=00-30:00            # time (DD-HH:MM)
#SBATCH --account=def-spai
#SBATCH --cpus-per-task=6
module --force purge
module load nixpkgs/16.09
module load gcc/7.3.0
module load python/3.8
module load scipy-stack/2019b
module load cuda/10.2
export LD_LIBRARY_PATH=/cvmfs/soft.computecanada.ca/easybuild/software/2017/Core/cudacore/10.2.89/lib64
source /project/6059997/BIONIC_ENV/bin/activate
cd <directory where the BIONIC/ is>
time python -m bionic.run -config bionic/config/patient_similarity.json # This is the example json file, can be changed based on your task.

3. Run sbatch <script_name>.sh
4. There should be a slurm.out file created that contains the output.
5. Once the script finishes, feature files will be under bionic/output/ folder. This will be used in post-BIONIC classification script. Please see https://github.com/RealPaiLab/DL_classifier for post-BIONIC scirpt. To run post-BIONIC classification script, please clone DL_classifier repo and use svm_classification.py or mlp_classification.py under DL_classifier.

How to run Semi-supervised BIONIC on Graham - Interactive Window

1. Clone the repo by doing git clone git@github.com:smilejennyyu/BIONIC.git
2. Create an interactive window for GPU job

salloc --account <account-name> --time <time-usage> --cpus-per-task=<num-cpus> --mem=<memory-usage> --gres=gpu:<num-gpus>

An example can be: salloc --account def-spai --time 00:30:00 --cpus-per-task=1 --mem=5G --gres=gpu:1

3. Load necessary modules on Graham

module load nixpkgs/16.09
module load gcc/7.3.0
module load llvm/7.0.0
module load python/3.8
module load scipy-stack/2019b
module load cuda/10.2

4. Specify cuda v10.2 path on Graham:

export LD_LIBRARY_PATH=/cvmfs/soft.computecanada.ca/easybuild/software/2017/Core/cudacore/10.2.89/lib64

5. Activate Python virtual environmentsource by doing source /project/6059997/BIONIC_ENV/bin/activate
6. Run python -m bionic.run -config <path_to_your_config_file.json> for your task. If you see Using CUDA, it means your program is using GPU.
7. Feature files will be under bionic/output/ folder. This will be used in post-BIONIC classification script. Please see https://github.com/RealPaiLab/DL_classifier for post-BIONIC scirpt. To run post-BIONIC classification script, please clone DL_classifier repo and use svm_classification.py or mlp_classification.py under DL_classifier.

Common Installation Issues

1. ValueError: numpy.ndarray size changed, may indicate binary incompatibility. Expected 88 from C header, got 80 from PyObject Solution: Make sure your numpy>=1.20.0 Reference: https://stackoverflow.com/questions/66060487/valueerror-numpy-ndarray-size-changed-may-indicate-binary-incompatibility-exp

2. ImportError: libgfortran.so.4: cannot open shared object file: No such file or directory Solution: unload everything and make sure you follow the EXACT SAME order as the step 3 in Run BIONIC on GPU Graham section. If it's still not working, contact Compute Canada Technical Support team.

Difference from the Original BIONIC

If you are curious about the changes we made, please search CHANGE ADDED in our BIONIC repo! Those comments with CHANGE ADDED are where we changed.

Check out the preprint!

💥 Introduction

BIONIC (Biological Network Integration using Convolutions) is a deep-learning based biological network integration algorithm that extends the graph convolutional network (GCN) to learn integrated features for genes or proteins across input networks. BIONIC produces high-quality gene features and is scalable both in number of networks and network size.

An overview of BIONIC can be seen below.

1. Multiple networks are input into BIONIC
2. Each network is passed through its own graph convolutional encoder where network-specific gene features are learned based the network topologies. These features are summed to produce integrated gene features which capture salient topological information across input networks. The integrated features can then be used for downstream tasks, such as gene-gene functional linkage prediction, module detection (clustering) and gene function prediction.
3. In order to train and optimize the integrated gene features, BIONIC first decodes the integrated features into a reconstruction of the input networks.
4. BIONIC then minimizes the difference between this reconstruction and the input networks (i.e. reconstruction error) by updating its weights to learn gene features that capture relevant topological information.

⚡ Usage

Configuration File

BIONIC runs by passing in a configuration file - a JSON file containing all the relevant model file paths and hyperparameters. You can have a uniquely named config file for each integration experiment you want to run. An example config file can be found here.

The configuration keys are as follows:

Argument	Default	Description
names	N/A	Filepaths of input networks. By specifying "*" after the path, BIONIC will integrate all networks in the directory.
out_name	config file path	Path to prepend to all output files. If not specified it will be the path of the config file. out_name takes the format path/to/output where output is an extensionless output file name.
delimiter	" "	Delimiter for input network files.
epochs	3000	Number of training steps to run BIONIC for (see usage tips).
batch_size	2048	Number of genes in each mini-batch. Higher numbers result in faster training but also higher memory usage.
sample_size	0	Number of networks to batch over (0 indicates all networks will be in each mini-batch). Higher numbers (or 0) result in faster training but higher memory usage.
learning_rate	0.0005	Learning rate of BIONIC. Higher learning rates result in faster convergence but run the risk of unstable training (see usage tips).
embedding_size	512	Dimensionality of the learned integrated gene features (see usage tips).
svd_dim	0	Dimensionality of initial network features singular value decomposition (SVD) approximation. 0 indicates SVD is not applied. Setting this to 1024 or 2048 can be a useful way to speed up training and reduce memory consumption (especially for integrations with many genes) while incurring a small reduction in feature quality.
initialization	"xavier"	Weight initialization scheme. Valid options are "xavier" or "kaiming".
gat_shapes.dimension	64	Dimensionality of each individual graph attention layer (GAT) head (see usage tips).
gat_shapes.n_heads	10	Number of attention heads for each network-specific GAT.
gat_shapes.n_layers	2	Number of times each network is passed through its corresponding GAT. This number corresponds to the effective neighbourhood size of the convolution.
save_network_scales	false	Whether to save the internal learned network features scaling coefficients.
save_model	true	Whether to save the trained model parameters and state.
use_tensorboard	false	Whether to output training data and feature embeddings to Tensorboard. NOTE: Tensorboard is not included in the default installation and must be installed seperately.
plot_loss	true	Whether to plot the model loss curves after training.

By default, only the names key is required, though it is recommended you experiment with different hyperparameters so BIONIC suits your needs.

Network Files

Input networks are text files in edgelist format, where each line consists of two gene identifiers and (optionally) the weight of the edge between them, for example:

geneA geneB 0.8
geneA geneC 0.75
geneB geneD 1.0

If the edge weight column is omitted, the network is considered binary (i.e. all edges will be given a weight of 1). The gene indentifiers and edge weights are delimited with spaces by default. If you have network files that use different delimiters, this can be specified in the config file by setting the delimiter key. BIONIC assumes all networks are undirected and enforces this in its preprocessing step.

Running BIONIC

To run BIONIC, do

$ bionic path/to/your_config_file.json

Results will be saved in the out_name directory as specified in the config file.

Usage Tips

The configuration parameters table provides usage tips for many parameters. Additional suggestions are listed below. If you have any questions at all, please open an issue.

Hyperparameter Choice

• learning_rate and epochs have the largest effect on training time and performance.
• learning_rate should generally be reduced as you integrate more networks. If the model loss suddenly increases by an order of magnitude or more at any point during training, this is a sign learning_rate needs to be lowered.
• epochs should be increased as you integrate more networks. 10000-15000 epochs is not unreasonable for 50+ networks.
• The reconstruction loss may look like it's bottoming out early on but the model will continue improving feature quality for an unintuitively long time afterward.
• embedding_size directly affects the quality of learned features. We found the default 512 works for most networks, though it's worth experimenting with different sizes for your application. In general, higher embedding_size will encode more information present in the input networks but at the risk of also encoding noise.
• gat_shapes.dimension should be increased for networks with many nodes. We found 128 - 256 is a good size for human networks, for example.

Input Networks

• BIONIC runs faster and performs better with sparser networks - as a general rule, try to keep the average node degree below 50 for each network.

📁 Datasets

Supplementary files can be found here.
