Pinkertons Surveillance Database

Website, database schema, and data loading scripts for Mapping the Pinkertons.

Database Schema Overview

• activities: Main table containing surveillance activities/events
• locations: Normalized location data (bars, neighborhoods, streets, etc.)
• activity_locations: Junction table linking activities to locations

Setup

Prerequisites

• PostgreSQL 12+
• Python 3.13+ (specified in .python-version)
• golang-migrate (for migrations)
• uv - Python package manager

Install uv and Dependencies

curl -LsSf https://astral.sh/uv/install.sh | sh

# After installing uv:
uv install

Database Creation

# Create database (if using dedicated database)
createdb detectives

# OR if using shared database (e.g., apiary)
# Just set DB_NAME in .env to the shared database name
# The migrations will create the 'detectives' schema within that database

Note: This project can work in a shared database (e.g., apiary) alongside other projects. It uses:

• A dedicated PostgreSQL schema: detectives
• A dedicated migration tracking table: detectives_schema_migrations

This prevents conflicts with other projects in the same database.

Environment Configuration

cp .env.example .env

Running Migrations

Migrations require the use of golang-migrate. You can use the Makefile targets which automatically use your .env configuration:

# Run migrations
make migrate-up

# Check migration version
make migrate-version

# Rollback if needed
make migrate-down

Migration Isolation: This project uses a custom migration tracking table (detectives_schema_migrations) to allow multiple projects to coexist in the same PostgreSQL database. The Makefile automatically includes x-migrations-table=detectives_schema_migrations in the database URL.

Troubleshooting Migrations:

• If you get "relation already exists" errors on a database where tables exist but migration tracking is missing, force the migration version:

  migrate -path db/migrations -database "$(DB_URL)&x-migrations-table=detectives_schema_migrations" force 4

• If migrations fail mid-way (dirty state), use migrate force <last_good_version> to reset

Loading Data

Run the loader

uv run utils/load_data.py data/el_paso.csv

The script will:

• Parse dates, times, and durations
• Convert Yes/No values to booleans
• Normalize and deduplicate locations
• Create activity-location relationships
• Show progress and summary statistics

Configuration

Database credentials are loaded from the .env file. The script uses these environment variables:

• DB_NAME - Database name (default: detectives)
• DB_USER - Database user (default: postgres)
• DB_PASSWORD - Database password (default: postgres)
• DB_HOST - Database host (default: localhost)
• DB_PORT - Database port (default: 5432)
• DB_SCHEMA - Database schema name (default: detectives)

The .env.example file includes commented sections for production, development, and local environments. Simply uncomment the block you want to use.

Data Notes

Duration Parsing

The script handles various duration formats:

• 5h45m → 5 hours 45 minutes
• 10h → 10 hours
• [10h total] → 10 hours (brackets and "total" removed)

Time Parsing

• Converts HH:MM format to time objects
• Ignores text values like "Evening", "Afternoon"

Boolean Fields

• Yes → true
• No → false
• Empty/other → null

Location Deduplication

Locations are matched on the combination of:

• locality
• street_address
• location_name

This prevents duplicate location records while allowing for nulls in any field.

Example Queries

Note: All queries must use the detectives schema prefix (e.g., detectives.activities).

-- Find all surveillance activities in Smeltertown
SELECT a.*, l.locality, l.location_name
FROM detectives.activities a
JOIN detectives.activity_locations al ON a.id = al.activity_id
JOIN detectives.locations l ON al.location_id = l.id
WHERE l.locality LIKE 'Smeltertown%';

-- Count activities by operative
SELECT operative, COUNT(*) as activity_count
FROM detectives.activities
WHERE operative IS NOT NULL
GROUP BY operative
ORDER BY activity_count DESC;

-- Find all activities at bars
SELECT a.date, a.mode, a.subject, l.location_name, l.locality
FROM detectives.activities a
JOIN detectives.activity_locations al ON a.id = al.activity_id
JOIN detectives.locations l ON al.location_id = l.id
WHERE l.location_type = 'Bar'
ORDER BY a.date;

-- Activities by date range
SELECT date, COUNT(*) as activity_count
FROM detectives.activities
WHERE date BETWEEN '1939-07-27' AND '1939-08-15'
GROUP BY date
ORDER BY date;
