Valkey Helm Chart

Helm chart for deploying Valkey on Kubernetes. Valkey is a high-performance, open-source data structure server compatible with Redis.

Features

Feature	Description
Standalone Mode	Simple single-instance deployment
Sentinel Mode	High availability with automatic failover
Authentication	Support for password and existing secrets
Persistence	Configurable persistent volumes
Metrics	Built-in Prometheus exporter
Security	SecurityContext, NetworkPolicies, RBAC
Automatic Upgrades	Pre-upgrade hooks for zero-downtime migrations
TLS	Support for encrypted connections

Requirements

Component	Version
Kubernetes	>= 1.23
Helm	>= 3.8

Image Versioning Strategy

This chart uses Chainguard's zero-CVE Valkey images for enhanced security.

Why `latest` tag?

Free tier limitation: Chainguard's free tier only provides the latest tag
Automatic updates: Using latest ensures you always get the most recent security patches
Zero CVEs: Chainguard images are rebuilt continuously to maintain zero known vulnerabilities

Version tracking

appVersion in Chart.yaml: Reflects the current Valkey version available in cgr.dev/chainguard/valkey:latest
Automated updates: A GitHub Action checks weekly for version updates and creates PRs automatically
Transparency: Every version change is tracked via pull requests and changelog entries

For production use

If you require version pinning for production:

# Override with a specific version (requires Chainguard Pro or alternative registry)
image:
  repository: valkey/valkey  # Official Valkey images
  tag: "9.0.0"               # Specific version tag

Note: Using latest provides continuous security updates but means deployments may pull different versions over time. For strict reproducibility, consider using image digests or switching to a registry that provides versioned tags.

Quick Start

# Add the repository
helm repo add valkey https://start-codex.github.io/valkey-helm-chart
helm repo update

# Install with default values
helm install my-valkey valkey/valkey

# Install with authentication
helm install my-valkey valkey/valkey \
  --set auth.enabled=true \
  --set auth.password="your-secure-password"

Architectures

Standalone (Default)

Simple deployment with a single Valkey instance. Ideal for development and workloads that don't require high availability.

+------------------+
|     Valkey       |
|   (standalone)   |
+------------------+
        |
+------------------+
|       PVC        |
+------------------+

helm install my-valkey valkey/valkey

Sentinel (High Availability)

Architecture with master, replicas, and sentinels for automatic failover. Recommended for production.

+------------------+     +------------------+     +------------------+
|     Sentinel     |     |     Sentinel     |     |     Sentinel     |
+------------------+     +------------------+     +------------------+
         |                       |                        |
         +-------------+---------+------------------------+
                       |
         +-------------+-------------+
         |             |             |
+--------v---+  +------v-----+  +----v-------+
|   Master   |  |  Replica   |  |  Replica   |
+------------+  +------------+  +------------+
      |              |               |
+-----v----+  +------v-----+  +-----v------+
|   PVC    |  |    PVC     |  |    PVC     |
+----------+  +------------+  +------------+

helm install my-valkey valkey/valkey \
  --set architecture=sentinel \
  --set sentinel.replicaCount=3 \
  --set replica.replicaCount=2

Configuration

Global Parameters

Parameter	Description	Default
`architecture`	Deployment mode: `standalone` or `sentinel`	`standalone`
`global.imageRegistry`	Global registry for all images	`""`
`global.storageClass`	Global StorageClass	`""`
`clusterDomain`	Kubernetes cluster domain	`cluster.local`


Parameter	Description	Default
`image.registry`	Image registry	`docker.io`
`image.repository`	Image repository	`valkey/valkey`
`image.tag`	Image tag	`9.0.0`
`image.pullPolicy`	Pull policy	`IfNotPresent`

Authentication

Parameter	Description	Default
`auth.enabled`	Enable authentication	`false`
`auth.password`	Password (not recommended for production)	`""`
`auth.existingSecret`	Name of existing Secret	`""`
`auth.existingSecretPasswordKey`	Password key in Secret	`password`

Standalone

Parameter	Description	Default
`standalone.replicaCount`	Number of replicas	`1`
`standalone.persistence.enabled`	Enable persistence	`true`
`standalone.persistence.size`	Volume size	`8Gi`
`standalone.persistence.storageClass`	StorageClass	`""`
`standalone.service.type`	Service type	`ClusterIP`
`standalone.service.port`	Service port	`6379`
`standalone.resources.requests.memory`	Memory request	`128Mi`
`standalone.resources.requests.cpu`	CPU request	`100m`
`standalone.resources.limits.memory`	Memory limit	`256Mi`

Sentinel

Parameter	Description	Default
`sentinel.replicaCount`	Number of sentinels	`3`
`sentinel.quorum`	Quorum for failover	`2`
`sentinel.downAfterMilliseconds`	Time to detect failure	`30000`
`sentinel.failoverTimeout`	Failover timeout	`180000`
`master.replicaCount`	Number of masters	`1`
`replica.replicaCount`	Number of replicas	`2`

Metrics

Parameter	Description	Default
`metrics.enabled`	Enable Prometheus exporter	`false`
`metrics.image.repository`	Exporter image	`oliver006/redis_exporter`
`metrics.image.tag`	Exporter tag	`v1.81.0`
`metrics.serviceMonitor.enabled`	Create ServiceMonitor	`false`
`metrics.podMonitor.enabled`	Create PodMonitor	`false`

Security

Parameter	Description	Default
`podSecurityContext.fsGroup`	Filesystem group	`999`
`podSecurityContext.runAsUser`	Container user	`999`
`securityContext.runAsNonRoot`	Run as non-root	`true`
`securityContext.readOnlyRootFilesystem`	Read-only filesystem	`true`
`networkPolicy.enabled`	Enable NetworkPolicy	`false`

Examples

Local Development

# values-dev.yaml
architecture: standalone
auth:
  enabled: false
standalone:
  persistence:
    enabled: false
  resources:
    requests:
      memory: 64Mi
      cpu: 50m
    limits:
      memory: 128Mi

helm install valkey-dev valkey/valkey -f values-dev.yaml

Production with Authentication

# values-prod.yaml
architecture: standalone
auth:
  enabled: true
  existingSecret: valkey-secret
  existingSecretPasswordKey: password
standalone:
  persistence:
    enabled: true
    storageClass: fast-ssd
    size: 50Gi
  resources:
    requests:
      memory: 1Gi
      cpu: 500m
    limits:
      memory: 2Gi
metrics:
  enabled: true
  serviceMonitor:
    enabled: true

# Create the secret first
kubectl create secret generic valkey-secret \
  --from-literal=password="your-super-secure-password"

# Install
helm install valkey-prod valkey/valkey -f values-prod.yaml

High Availability with Sentinel

# values-ha.yaml
architecture: sentinel
auth:
  enabled: true
  password: "ha-password"

sentinel:
  replicaCount: 3
  quorum: 2
  resources:
    requests:
      memory: 128Mi
      cpu: 100m

master:
  persistence:
    enabled: true
    size: 20Gi
  resources:
    requests:
      memory: 512Mi
      cpu: 250m
    limits:
      memory: 1Gi

replica:
  replicaCount: 2
  persistence:
    enabled: true
    size: 20Gi
  resources:
    requests:
      memory: 512Mi
      cpu: 250m
    limits:
      memory: 1Gi

metrics:
  enabled: true
  serviceMonitor:
    enabled: true

helm install valkey-ha valkey/valkey -f values-ha.yaml

With Network Policies

# values-secure.yaml
architecture: standalone
auth:
  enabled: true
  existingSecret: valkey-secret

networkPolicy:
  enabled: true
  allowExternal: false
  ingressNSMatchLabels:
    app: my-app

Connecting to Valkey

From Inside the Cluster

# Temporary pod for testing
kubectl run valkey-client --rm -it \
  --image=valkey/valkey:9.0.0 \
  -- valkey-cli -h my-valkey

# With authentication
kubectl run valkey-client --rm -it \
  --image=valkey/valkey:9.0.0 \
  -- valkey-cli -h my-valkey -a "your-password"

Port-forward for Local Access

kubectl port-forward svc/my-valkey 6379:6379

# In another terminal
valkey-cli -h localhost -p 6379

Sentinel - Get Current Master

kubectl run valkey-client --rm -it \
  --image=valkey/valkey:9.0.0 \
  -- valkey-cli -h my-valkey-sentinel -p 26379

# Useful sentinel commands
> SENTINEL masters
> SENTINEL get-master-addr-by-name mymaster
> SENTINEL replicas mymaster

Upgrades

This chart includes an automatic upgrade mechanism that handles StatefulSets transparently, avoiding immutable field errors.

How It Works

Pre-upgrade Hook: Deletes StatefulSets with --cascade=orphan, preserving pods and PVCs
Recreation: Helm recreates StatefulSets with new configuration
Rolling Update: Pods are updated gradually

Upgrading the Chart

# Update repository
helm repo update

# View available versions
helm search repo valkey/valkey --versions

# Upgrade to latest version
helm upgrade my-valkey valkey/valkey

# Upgrade with new values
helm upgrade my-valkey valkey/valkey -f new-values.yaml

# Upgrade Valkey image
helm upgrade my-valkey valkey/valkey --set image.tag=9.0.0

Hook Configuration

preUpgradeHook:
  image:
    registry: docker.io
    repository: alpine/k8s
    tag: "1.31.13"
  resources:
    limits:
      memory: 128Mi
    requests:
      cpu: 50m
      memory: 64Mi

Monitoring

Enable Prometheus Metrics

metrics:
  enabled: true
  serviceMonitor:
    enabled: true
    interval: 30s
    scrapeTimeout: 10s

Available Metrics

Metric	Description
`redis_up`	Server status
`redis_connected_clients`	Connected clients
`redis_memory_used_bytes`	Memory used
`redis_commands_processed_total`	Processed commands
`redis_keyspace_hits_total`	Cache hits
`redis_keyspace_misses_total`	Cache misses

Grafana Dashboard

You can use the official Redis Exporter dashboard: Grafana Dashboard 763

Security

Production Recommendations

Use external Secrets for passwords:

auth:
  enabled: true
  existingSecret: my-valkey-secret

Enable Network Policies:

networkPolicy:
  enabled: true
  allowExternal: false

Configure resources:

standalone:
  resources:
    limits:
      memory: 2Gi
    requests:
      memory: 1Gi

Enable TLS (if needed):

tls:
  enabled: true
  existingSecret: valkey-tls-secret

Default Security Context

podSecurityContext:
  fsGroup: 999
  runAsUser: 999
  runAsGroup: 999

securityContext:
  allowPrivilegeEscalation: false
  capabilities:
    drop:
      - ALL
  readOnlyRootFilesystem: true
  runAsNonRoot: true

Troubleshooting

Pod Won't Start

# View events
kubectl describe pod my-valkey-0

# View logs
kubectl logs my-valkey-0

# Check PVC
kubectl get pvc

Connection Error

# Check service
kubectl get svc my-valkey

# Check endpoints
kubectl get endpoints my-valkey

# Connectivity test
kubectl run test --rm -it --image=busybox -- nc -zv my-valkey 6379

StatefulSet Upgrade Error

If the pre-upgrade hook fails, you can delete manually:

kubectl delete statefulset my-valkey --cascade=orphan
helm upgrade my-valkey valkey/valkey

Check Sentinel Status

kubectl exec -it my-valkey-sentinel-0 -- valkey-cli -p 26379 SENTINEL masters

Uninstallation

# Uninstall release
helm uninstall my-valkey

# Delete PVCs (WARNING: this deletes data)
kubectl delete pvc -l app.kubernetes.io/instance=my-valkey

Development

Test Locally

# Validate syntax
helm lint .

# Render templates
helm template test . --debug

# Dry-run
helm install test . --dry-run --debug

# Install in test namespace
helm install test . -n valkey-test --create-namespace

Run Tests

helm test my-valkey

Contributing

Fork the repository
Create a branch (git checkout -b feature/new-feature)
Commit your changes (git commit -am 'Add new feature')
Push to branch (git push origin feature/new-feature)
Create a Pull Request

Links

License

This project is licensed under Apache 2.0.

Made with ❤️ by StartCodex

Name		Name	Last commit message	Last commit date
Latest commit History 114 Commits
.github		.github
templates		templates
.gitignore		.gitignore
.helmignore		.helmignore
CHANGELOG.md		CHANGELOG.md
Chart.yaml		Chart.yaml
README.md		README.md
artifacthub-repo.yml		artifacthub-repo.yml
public-key.asc		public-key.asc
values.schema.json		values.schema.json
values.yaml		values.yaml

Folders and files

Latest commit

History

Repository files navigation

Valkey Helm Chart

Table of Contents

Features

Requirements

Image Versioning Strategy

Why latest tag?

Version tracking

For production use

Quick Start

Architectures

Standalone (Default)

Sentinel (High Availability)

Configuration

Global Parameters


Authentication

Standalone

Sentinel

Metrics

Security

Examples

Local Development

Production with Authentication

High Availability with Sentinel

With Network Policies

Connecting to Valkey

From Inside the Cluster

Port-forward for Local Access

Sentinel - Get Current Master

Upgrades

How It Works

Upgrading the Chart

Hook Configuration

Monitoring

Enable Prometheus Metrics

Available Metrics

Grafana Dashboard

Security

Production Recommendations

Default Security Context

Troubleshooting

Pod Won't Start

Connection Error

StatefulSet Upgrade Error

Check Sentinel Status

Uninstallation

Development

Test Locally

Run Tests

Contributing

Links

License

About

Resources

Uh oh!

Stars

Watchers

Forks

Releases

Packages 0

Uh oh!

Contributors

Uh oh!

Languages

Why `latest` tag?

Packages
