Capybara-Captcha

A flexible, lightning-quick, privacy-friendly CAPTCHA powered by Cloudflare Workers + KV. Capybara-Captcha uses a SHA-256 proof-of-work (PoW) challenge instead of user tracking, making it simple to integrate and friendly for humans.

Highlights

• Serverless & fast: Single-file Worker with Cloudflare KV for storage
• Privacy-first: No cookies or tracking
• Payload token binding: Prevents replay/cross-app misuse
• Self-contained: No dependency on upstream; can clone itself
• Easy deploy: One-click button or simple Wrangler commands

---

One-Click Deploy

Click to deploy this Worker to your Cloudflare account. The flow will guide you to create/bind KV and deploy.

After deploy, note your public URL, e.g. https://your-worker.yourname.workers.dev.

---

Quick cURL Examples

Replace BASE with your Worker URL.

• Create challenge (difficulty 3, duration 30s):

BASE="https://your-worker.yourname.workers.dev"
curl -sS -X POST "$BASE/api/challenge" \
  -H 'Content-Type: application/json' \
  -d '{"difficulty":3,"duration":30}' | jq .

• Verify solution (fill placeholders):

curl -sS -X POST "$BASE/api/verify" \
  -H 'Content-Type: application/json' \
  -d '{"id":"<challenge_id>","solution":"<number>","payload_token":"<payload_from_challenge>"}' | jq .

• Poll challenge status:

curl -sS "$BASE/api/challenge/<challenge_id>" | jq .

---

Manual Deploy (Wrangler)

Prerequisites: Node.js and wrangler.

1. Create KV namespace and bind in wrangler.jsonc as CAPY_GUEST_KV (id + preview_id)

wrangler kv namespace create CAPY_GUEST_KV
wrangler kv namespace create CAPY_GUEST_KV --preview

2. Configure wrangler.jsonc

• REDIRECT_URL: redirect for /
• Limits: DEFAULT_DIFFICULTY, MIN_DIFFICULTY, MAX_DIFFICULTY, DEFAULT_DURATION_SEC, MIN_DURATION_SEC, MAX_DURATION_SEC, LIMIT_MAX_CHALLENGES_PER_DAY
• Namespacing: KV_PREFIX_BASE, INSTANCE_ID

3. Run locally

wrangler dev --local --port 8789 --config wrangler.jsonc | cat

4. Deploy

wrangler deploy --config wrangler.jsonc

---

How It Works

1. Client requests a PoW challenge. Server creates and stores it in KV, returns { id, nonce, difficulty, payload_token }.
2. Client finds a solution so sha256(nonce + solution) has leading zeros per difficulty.
3. Client submits { id, solution, payload_token } for verification.
4. Server validates payload_token and PoW, marks challenge solved, and responds.

Payload tokens are short strings signed by a secret. The secret is automatically generated and persisted in KV on first run (can be overridden with environment secret TOKEN_SECRET).

---

API Reference

Base URL example: https://your-worker.yourname.workers.dev

• POST /api/challenge
  • Body (JSON, optional): { difficulty?: number, duration?: number }
  • Response (JSON):

{
  "challenge": { "id": "...", "nonce": "...", "type": "pow", "difficulty": 3 },
  "status": "in-progress",
  "progress": 0,
  "expires_in": 30,
  "payload_token": "..."
}

• GET /api/challenge/:id
  • Response example:

{
  "challenge": { "id": "...", "nonce": "...", "type": "pow", "difficulty": 3 },
  "status": "in-progress",
  "progress": 42,
  "expires_in": 18
}

• POST /api/verify
  • Body (JSON): { id: string, solution: string, payload_token: string }
  • Response example (success):

{ "status": "solved", "verified": true, "progress": 100 }

• GET /dev: Small info endpoint with limits and version.

---

Quick Integration Examples

Vanilla JS (Browser)

<script>
const BASE_URL = 'https://your-worker.yourname.workers.dev';

async function sha256(s){
  const h = await crypto.subtle.digest('SHA-256', new TextEncoder().encode(s));
  return Array.from(new Uint8Array(h)).map(b=>b.toString(16).padStart(2,'0')).join('');
}
function hasZeros(hex, n){ return hex.slice(0, n) === '0'.repeat(n); }

async function runCaptcha(){
  const res = await fetch(BASE_URL + '/api/challenge', { method: 'POST', headers: { 'Content-Type': 'application/json' }, body: JSON.stringify({ difficulty: 3, duration: 30 }) });
  const data = await res.json();
  const { challenge, payload_token } = data;

  let sol = 0;
  while(true){
    const h = await sha256(challenge.nonce + sol);
    if (hasZeros(h, challenge.difficulty)) break;
    sol++;
  }

  const vr = await fetch(BASE_URL + '/api/verify', { method: 'POST', headers: { 'Content-Type': 'application/json' }, body: JSON.stringify({ id: challenge.id, solution: String(sol), payload_token }) });
  const out = await vr.json();
  console.log('verify:', out);
}
</script>

React/Next Component

See Resources/captcha.tsx for a simple TSX button component that starts the challenge, solves PoW, and verifies.

Backend Example (Node/Express)

// Server receives frontend's verify result to proceed with protected action
app.post('/submit', async (req, res) => {
  const { id, solution, payload_token } = req.body;
  const r = await fetch(process.env.CAPY_BASE_URL + '/api/verify', {
    method: 'POST', headers: { 'Content-Type': 'application/json' },
    body: JSON.stringify({ id, solution, payload_token })
  });
  const v = await r.json();
  if (!v.verified) return res.status(403).json({ error: 'captcha_failed' });
  // proceed
  res.json({ ok: true });
});

---

Configuration

Edit wrangler.jsonc:

• REDIRECT_URL: redirect target for /
• DEFAULT_DIFFICULTY, MIN_DIFFICULTY, MAX_DIFFICULTY
• DEFAULT_DURATION_SEC, MIN_DURATION_SEC, MAX_DURATION_SEC
• LIMIT_MAX_CHALLENGES_PER_DAY
• KV_PREFIX_BASE, INSTANCE_ID

KV binding: CAPY_GUEST_KV must be configured with id and preview_id.

Secret management: a signing secret is auto-generated and stored in KV on first run. Optionally override with an environment secret TOKEN_SECRET.

---

Troubleshooting

• 404 on /api/*: verify base URL and paths
• Rate limit not working: ensure KV binding exists and LIMIT_MAX_CHALLENGES_PER_DAY > 0
• CORS: Worker replies with permissive CORS (*) for demo purposes

---

FAQ

• Dependent on upstream? No, this worker is standalone and can self-clone
• Multiple deployments? Yes. Set unique INSTANCE_ID per deployment
• Data residency? Uses Cloudflare KV; your account/region policies apply

---

Architecture at a Glance

[Website / App]
        |
        v
   [Public URL]
https://your-worker.yourname.workers.dev
        |
        v
   [Cloudflare Worker]
        |
   -----------------
   |               |
   v               v
[KV: CAPY_GUEST_KV]  [Challenge Logic]
   |                  |
   v                  v
Per-IP Limits      Generate/Verify
Storage            Challenge Data

Lifecycle

1) POST /api/challenge -> Store challenge -> Return challenge + payload_token
2) Client solves PoW
3) POST /api/verify -> Validate token + PoW -> Mark solved
